• Reliable power protection: Provides continuous and clean power with high efficiency (up to 95%).
• Efficient output: With a power factor of 0.9, which provides optimal energy protection for IT equipment.
• Connectivity: Possibility to connect up to 4 devices in parallel to increase power or improve security
• Low input current distortion: The device maintains very low levels of current distortion - below 1.5% at full load and below 5% at 10% load.
• Battery monitoring (Batt-Watch)
• Eco-mode operation: Optimization of consumption without sacrificing performance.
• Extensive management and monitoring: 7-inch color touch screen (standard from 80 kVA, optional for 60 kVA) with multiple communication interfaces for efficient management.
• Battery Cabinet Options
• Communication Interfaces: Includes RS232 and USB-HID, as well as a smart SNMP slot.
• Technology: Online, double conversion with DSP control
• Input voltage: 220 / 230 / 240 V, 3 x 380 / 3 x 400 / 3 x 415 V (3P + N)
• Voltage range: +15% / -20% (configurable)
• Nominal frequency: 50 / 60 Hz
• Total harmonic distortion (THDi):
At 100% load: <1.5%
At 50% load: <2.5%
At 10% load: <6.0%
• Power factor: 0.9
• Efficiency:
In Eco-mode: 95%
In online mode: 92.0% - 95.0% (depending on load)
• Permissible overloads:
125% for 10 min
150% for 60 s
150% for 20 ms
• Communication ports: 1 x RS232/RS485, 1 x USB (Modbus protocol)
• Noise level:
• Operating temperature: 0°C to +40°C
• Maximum altitude: 2400 m
