Technical file: Pytes V5°
For quantities of 12 pieces, a discount can be applied upon negotiation. For a specific offer, please send an inquiry through the contact form on the website or get in touch with us by phone.
High-performance LFP (Lithium Iron Phosphate) battery for home and business energy storage systems. It helps save on electricity bills during peak hours and provides reliable backup power during outages. Compatible with energy stored from solar panels or directly from the grid.
Specifications
-
Nominal voltage: 51.2 V
-
Voltage range: 47.5–57.6 V
-
Nominal capacity: 100 Ah
-
Nominal energy: 5.12 kWh
-
Recommended charge/discharge current: 75 A
-
Max continuous charge/discharge current: 100 A
-
Peak discharge current: 180 A (15 s)
-
Cycle life: ≥ 6000 cycles @ 90% DoD (80% capacity retention at 25 °C)
-
Round-trip efficiency: > 95%
-
Connection options: PHOENIX M6 Bolt
-
Compatibility: Works with most inverter brands, closed-loop with Sol-Ark
-
Communication ports: CAN, RS485, WiFi (remote monitoring & upgrading)
-
Certifications: UL9540, UL9540A, UL1973, IEC62619, CE, UN38.3, CEC, SGIP
-
Dimensions: 442 × 530 × 140 mm (3.2U)
-
Weight: 44 kg / 97 lbs
-
Operating temperature: −10 °C to +50 °C (with heating pad −18 °C to 50 °C)
-
Scalability: Up to 16 units (81.92 kWh) per group, 6 groups with hub (491.52 kWh total)
-
Warranty / Design life: 10 years warranty, up to 20 years design life
